Technical Data
Rated Power: MF 300W RMS, HF 80W RMS
Program Power: MF 600W RMS, HF 160W RMS
Component: LF 1x10inch + 2 x 1.7inch Neo
Connection: 2 x Neutrik Speakon (4 Pins)
Sensitivity (1W @ 1M): 95dB
Maximum SPL: 122dB Peak @ 1M
Impedance: 8Ohm
Frequency Range: 70 Hz ~ 20 KHz
Horn Dispersion: V 120 x H 10 Degree
Color: Black or White
N. Weight: 30kgs
Dimension (W x D x H): 560 x 400 x 299mm
Dimension (W x D x H): 495 x 395 x 665mm
Rec. Amplifier Power: HF 600W & LF: 900W 8Ohm
Applications: Concert Halls. Stadiums & Arenas. Discotheques,Touring Sound Reinforcement etc.
