LT-212
This element is designed to use in multiples. Up to 16 units can be arrayed to achieve extreme high levels needed for larger venues. The integrated rigging system allows quick and easy flying or ground stacking. The cabinet is built with top quality Birch-plywood at 11 layers, and coated with durable water resistant paint for an In-door or Out-door applications.
This line array system provides with complete amplification set, just need three steps then you can start to play the music. Step 1: Hang up or stack well the speakers, Step 2: Connect the cables, Step 3: Turn on the amplifiers and processor, start to play.
Flight cases and water-proof cover bags available for protecting the equipment.

Technical Data

Rated Power: LF 700W RMS, HF 120W RMS
Program Power: LF 14000W RMS, HF 240W RMS
Component: LF 2x12inch + HF 2 x 1.7inch
Connection: 2 x Neutrik Speakon (4 Pins)
Sensitivity (1W @ 1M): 103dB
Maximum SPL: 133dB Peak @ 1M
Impedance: 8 Ohm
Frequency Range: 60 Hz ~ 20 KHz
Horn Dispersion: V 10 x H 90 degree
Color: Black / White / Grey
N.Weight: 54kgs
Dimension (W x D x H): 1040 x 510 x 384mm
Dimension (W x D x H): 605 x 465 x 1135mm
Rec. Amplifier Power: HF 600W, LF 1250W 8Ohm
Applications: Concert Halls,Stadiums & Arenas, Discotheques,Touring Sound Reinforcement etc.
